Attributes

DCRS-5960-28F

DCRS-5960-52F

Ports

12 GE SFP ports,

44 GE SFP ports,

12 COMBO (SFP/GT)

4 COMBO (SFP/GT)

2 slots and max 4 10GE,

2 slots and max 4 10GE,

Performance

Switching Capability

128Gbps

176Gbps

Throughput

96Mpps

131Mpps

MAC Address

Max 16K

Max 16K

VLAN Table

Max 4K

Max 4K

ACL TABLE

Max 3k

Max 3k

Routing Table

Max 13k

Max 13k

L3 Interface

Max 1K

Max 1K

VRF interface

Max 255

Max 255

Port Queues

8

8

Physical

Dimension(WHD)

415mm×44mm×325mm

415mm×44mm×325mm

Relative Humidity

5% ~ 90%,

5% ~ 90%,

non-condensing

non-condensing

Operating Temperature

0℃ ~ 50℃

0℃ ~ 50℃

Storage Temperature

-40℃ ~ 70℃

-40℃ ~ 70℃

Power

AC: 100- 240V, 50-60Hz

AC: 100- 240V, 50-60Hz

DC: -48V

DC: -48V

Power Consumption

130W

180W

MTBF

>80,000 hours

>80,000 hours

MEF Comply

Comply MEF 9,14

Comply MEF 9,14

EMC safety

FCC, CE, RoHS,

FCC, CE, RoHS

Feature

Forwarding Mode

Storage and forwarding

L2 Features

IEEE802.3(10Base-T)

IEEE802.3u(100Base-TX)

IEEE802.3z(1000BASE-X)

IEEE802.3ab(1000Base-T)

IEEE802.3ae(10GBase)

9k Jumbo Frame

Port loopback detect

LLDP and LLDP-MED

UDLD

DDM

VCT

Support LACP 802.3ad, max 128 group trunk with max 8 ports for each trunk,

Support load balance

IEEEE802.1d(STP)

IEEEE802.1W(RSTP)

IEEEE802.1S(MSTP) Max 48 instance

Root Guard

BPDU Guard

BPDU forwarding

Support one to one or any to one port mirror

RSPAN

IGMP v1/v2/v3 Snooping and L2 query

ND snooping

MLDv1/v2 snooping

QinQ, GVRP, Broadcast / Multicast / Unicast Storm Control

Port/ MAC/ IP segment/ Portocol/ Voice/ Private/ Vlan support

Multicast Vlan Register/MVR for IPv4 and IPv6 service

Support port-based 802.1Q, 4096 VLAN

MAC filter, MAC limit

L3 Features

IP Protocol(IP support both of IPv4 and IPv6)

Support manual configure IPv4/IPv6 tunnel

Support 6to4 tunnel

Support ISATAP tunnel

Default Routing, Static Routing, Black hole route, VLSM and CIDR,

RIPv1/V2, OSPFv2, BGP4, support MD5 authentication LPM Routing

OSPFv3, BGP4+

Policy based Routing(PBR) for IPv4 and IPv6

VRRP, VRRP v3

PIM-DM, PIM-SM, PIM-SSM, MSDP

Static Multicast route

PIM-SM/DM/SSM for IPv6, 6 to 4 Tunnels, configured Tunnels, ISATAP

Multicast receive control

Illegal multicast source detect

Any cast RP for Ipv4 and Ipv6

Support ECMP(Equal Cost Multi-Path)with maxim 8 groups

URPF for IPv4 and IPv6

Support BFD

ARP guard, Local ARP proxy, Proxy ARP, ARP binding, Gratuitous ARP, ARP limit

QoS

8 queues per port

Support traffic classification based on IEEE 802.1p, ToS, port and DiffServ

Support SP, WRR.SWRR

Support Traffic Shaping

Support PRI Mark/Remark

ACL

Support standard and expanded ACL

Support IP ACL and MAC ACL

Support ACL based on source/definition IP, MAC, L3 IP, TCP/UDP port number, IP PRI(DSCP, ToS, Precedence), Time

Support time-based security auto-negotiation

ACL rules can be configured to port, VLAN, VLAN routing interfaces

Can be used for QoS classification

Reliability

Support MSTP(802.1s)

Support VRRP, LACP load balance

MRPP - Multi-layer Ring Protection Protocol

Redundant power supply, power load balancing

Support Firmware & Configure dual fault tolerance backup

DHCP

DCHP Client, Relay, Snooping, Option 82

DHCP Server for IPv4 and IPv6

DHCP v6 and DHCP snooping V6

Security

802.1X

Support guest Vlan and auto Vlan

MAB

GRE tunnel

BPDU tunnel

Management

CLI, Console(RS-232), Telnet (Ipv4/Ipv6), SSH(Ipv4/Ipv6),SSL connection

Support WEB based NMS

Support SNMPv1/v2c/v3 for IPv4, SNMPv1/v2c for IPv6

Strict management hosts by ACL

AAA or Local Authentication

SNTP and NTP, Daylight Saving time

Configuration file backup

Multiple configuration files

Support FTP/TFTP server or client upgrade

Support X-modem protocol upgrade

Support max 24 units cluster with 10GE ports and managed by single IP

Support 802.1 ah OAM

Supervision and Trouble Shooting

Supervise abnormity of task, memory, CPU, stack, switch chip, temperature and raise alarm

Mirror based on port and flow, RSPAN

Syslog

Sflow for IPv4 and IPv6

RMON 1, 2, 3, 9

Ping and trace route command

Product

Description

DCRS-5960-52F

10G IPv6 Routing Switch, 44* GE SFP and 4 Gigabit Combo (SFP/GT) ports and 2 slot, AC+DC redundant power supply

DCRS-5960-28F

10G IPv6 Routing Switch, 12* GE SFP and 12 Gigabit Combo (SFP/GT) ports and 2 slot, AC+DC redundant power supply

MRS-2XFP

DCRS-5960F series 2* 10G module(XFP interface) for DCRS-5960F series

MRS-2SFP+

DCRS-5960F series 2* 10G module(SFP+ interface) for DCRS-5960F series
