Features
|
|
Forwarding
|
Storage and forwarding
|
|
L2 Features
|
IEEE802.3(10Base-T)
|
|
IEEE802.3u(100Base-TX)
|
|
IEEE802.3z（1000BASE-X）
|
|
IEEE802.3ab（1000Base-T）
|
|
IEEE802.3ae（10GBase）
|
|
Loopback interface
|
|
9k Jumbo Frame
|
|
Port loopback detect
|
|
LLDP and LLDP-MED
|
|
UDLD
|
|
Support LACP 802.3ad, max 128 group trunk with max 8 ports for each trunk,
|
|
Support link aggregation by manual
|
|
IEEEE802.1d(STP)
|
|
IEEEE802.1W(RSTP)
|
|
IEEEE802.1S(MSTP) Max 48 instance
|
|
Root Guard
|
|
Bpdu Guard
|
|
Bpdu forwarding
|
|
Support one to one or any to one mirror
|
|
Support mirror cross business boards
|
|
Support RSPAN
|
|
IGMP v1/v2/v3, IGMP v1/v2/v3 Snooping, IGMP proxy
|
|
ICMPv6, ND, ND snooping, MLDv1/v2, MLDv1/v2 snooping
|
|
Support GVRP
|
|
Port/ MAC/ IP segment/ Portocol/ Voice/ Private/ Vlan support
|
|
Multicast Vlan register/MVR for IPv4 and IPv6
|
|
Support port-based 802.1Q, 4K VLAN
|
|
Support QinQ and selective QinQ
|
|
DFI/Broadcast/Multicast strome control
|
|
MAC binding(Ipv4 /Ipv6), MAC filter, MAC limit,
|
|
IP source guard
|
|
Port binding(Ipv4 /Ipv6)
|
|
Support smart link (or named flexible link)
|
|
L3 Features
|
IP Protocol（IP support both of IPv4 and IPv6）
|
|
Default Routing, Static Routing, Black hole route, VLSM and CIDR,
|
|
RIPv1/V2, OSPFv2, BGP4, support MD5 authentication LPM Routing
|
|
OSPFv3, BGP4+ support
|
|
Policy based Routing(PBR) for IPv4 and IPv6
|
|
Support 4 byte BGP AS number
|
|
Support GR for OSPF and BGP
|
|
VRRP, VRRP v3
|
|
DVMRP, PIM-DM, PIM-SM, PIM-SSM
|
|
Support MSDP(Multicast Source Discovery Protocol)
|
|
Static Multicast route
|
|
Multicast edge configure
|
|
Any cast RP for Ipv4 and Ipv6
|
|
PIM-SM/DM/SSM for IPv6, 6 to 4 Tunnels, configured Tunnels, ISATAP
|
|
Multicast receive control
|
|
Illegal multicast source detect
|
|
URPF for IPv4 and IPv6
|
|
Support BFD
|
|
Support ECMP（Equal Cost Multi-Path）with maxim 8 groups
|
|
ARP guard, Local ARP proxy, Proxy ARP, ARP binding, Gratuitous ARP, ARP limit
|
|
Tunnel technical
|
Support manual configure IPv4/IPv6 tunnel
|
|
Support 6to4 tunnel
|
|
Support ISATAP tunnel
|
|
Support GRE tunnel
|
|
MPLS
|
Support 255 VRF/VFI
|
|
Support LDP
|
|
L3 MPLS VPN
|
|
L2 VLL/VPLS
|
|
MPLS/VPLS proxy
|
|
MPLS-TE/FRR*
|
|
Support cross domain MPLS VPN
|
|
Support MPLS QOS
|
|
supported by software upgrade in future
|
|
QoS
|
8 hardware queues per port
|
|
Support traffic classification based on IEEE 802.1p, ToS, port and DiffServ
|
|
Support SP, WRR.SWRR
|
|
Support Traffic Shaping
|
|
Support rate limit for import and export
|
|
Support PRI Mark/Remark
|
|
Support WRED
|
|
Support 2 buckets with dual rate and triply color mark
|
|
ACL
|
Support standard and expanded ACL
|
|
Support IP ACL and MAC ACL,
|
|
Support ACL based on source/definition IP, MAC, L3 protocol, TCP/UDP port number, IP PRI(DSCP, ToS, Precedence), Time
|
|
Support ingress and egress ACL
|
|
ACL-X
|
Support time-based security auto-negotiation
|
|
ACL rules can be configured to port, VLAN, VLAN routing interfaces
|
|
Can be used for QoS classification
|
|
Anti-attack and Security
|
S-ARP: ARP inspection, defense ARP-DOS attack and address clone
|
|
Anti-Sweep: prevent ping Sweep
|
|
S-ICMP: resist PING-DOS attack, ICMP unreachable attack
|
|
S-Buffer: prevent DDOS attack
|
|
Switch engine CPU protection
|
|
Key message priority: secure processing of key legal messages
|
|
Port credit: inspect illegal DHCP Server, Radius Server. Connection via credit port only
|
|
Advanced LPM: filter “Bluster”, “zero day” and ”SQL slammer warm”
|
|
Support URPF, avoid IP address clone
|
|
All the above technologies efficiently prevent various DOS attack (e.g. ARP, Synflood, Smurf, ICMP attack), support ARP monitoring, defense Worm, Bluster, check sweep and raise alarm
|
|
DHCP
|
Support DCHP Client, Relay, Snooping, Option 82
|
|
DHCP Server for IPv4 and IPv6
|
|
DHCP v6 and DHCP snooping V6
|
|
DNS
|
DNS Client
|
|
DNS proxy
|
|
Ring Protocol
|
MRPP (Multi-Ring Protect Protocol)
|
|
Access security
|
802.1X
|
|
Port, MAC, username based
|
|
Support account based on time length and traffic
|
|
Support guest vlan and auto vlan
|
|
Work with private client can manage P2P traffic
|
|
MAC Based AAA(Client free access)
|
|
PPPOE/PPPOE+ forwarding
|
|
AAA
|
Support RADIUS AAA for IPV4 and IPv6
|
|
TACACS+ AAA
|
|
Configuration and Management
|
Support CLI, Telnet, WEB, SSH and SSL
|
|
Support SNMPv1/v2c/v3
|
|
Support MIB
|
|
Support RMON 1, 2, 3, 9
|
|
Power Saving Technology
|
Support reduce power consumption, improve cooling and reliability
|
|
Flexible fan and port management to save power consumption
|
|
SysLog
|
Support save syslog and trap to local device or server
|
|
Support max 8 servers for syslog or trap receive
|
|
NMS
|
Strict access control by ACL and QOS
|
|
Access the switch through AAA or Local Authentication
|
|
Support SNTP and NTP
|
|
Setup time zone and Daylight Saving time
|
|
Supervision and Trouble Shooting
|
Supervise abnormity of task, memory, CPU, stack, switch chip, temperature and raise alarm
|
|
Support Sflow
|
|
Support IPFIX (IP Flow Information Export)
|
|
Ping and trace route command
|
|
Configuration Management
|
Configuration file storage
|
|
Command operation log
|
|
Support dual images and files startup
|
|
Support FTP/TFTP server or client upgrade
|
|
Support X-modem protocol transfer the file
|
|
OAM
|
Support 802.3ah
|
|
Support 802.1ag
|
|
Physical
|
|
Dimension(W x D x H)
|
482.6x450x708.4 mm(16U)
|
482.6x450x841.7 mm(19U)
|
|
Relative Humidity
|
10%～90%, non-condensing
|
|
Storage Temperature
|
-40℃～70℃
|
|
Operating Temperature
|
0°C～40°C
|
|
Power
|
AC: Input 200~240V, 50~60 Hz;
|
AC: Input 90~260V, 50~60 Hz:
|
|
Power Consumption
|
≤900W
|
≤1600W
|
|
MTBF
|
>250,000 hours
|
>250,000 hours
|
|
MEF Comply
|
Comply MEF 9,14
|
Comply MEF 9,14
|
|
MEF Comply
|
Comply MEF 9,14
|
Comply MEF 9,14
|
