Camera IP ACTi A310 4MP Camera IP ACTi A310 4MP 4 Megapixel
Ngày & Đêm với độ nhạy sáng cao và đèn LED IR thích ứng
Ống kính cố định với f2.8mm / F1.6
Extreme WDR
S001089 IP Camera Số lượng: 1 Cái

Camera IP ACTi A310 4MP

Cloud Zoom small image
  • 4 Megapixel
    Ngày & Đêm với độ nhạy sáng cao và đèn LED IR thích ứng
    Ống kính cố định với f2.8mm / F1.6
    Extreme WDR

Mini Bullet 4MP với D / N, IR thích ứng, Extreme WDR, SLLS, Ống kính cố định, f2.8mm / F1.6 (HOV: 103 °), H.265 / H.264, 1080p / 30fps, 3D DNR, MicroSD / MicroSDHC / MicroSDXC, PoE / PCB, IP67, IK10 (vỏ kim loại)

Device

Product Type Mini Bullet
Maximum Resolution 4MP
Application Environment Outdoor
Image Sensor Progressive Scan CMOS
Sensor Size 1/2.7 "
Day / Night Yes
Low Light Sensitivity Superior
Minimum Illumination Color: 0.018 lux; B/W: 0 lux (IR LED on)
Color to B/W Switch ISP based switch, configurable
Mechanical IR Cut Filter Yes
IR LED Adaptive IR LED (850 nm)
IR Working Distance 65m (1.0 lux)
Electronic Shutter 1/5-1/64000 second (manual mode); 1/5-1/64000 second (auto mode)

Lens

Focal Length Fixed focal, f2.8mm
Aperture F1.6
Iris Fixed iris
Focus Fixed focus
Lens Mount Board mount
Horizontal Viewing Angle 103°
Vertical Viewing Angle 58°

Video

Compression H.265, H.264 (Main/ High profile), MJPEG
Maximum Frame Rate vs. Resolution 25 fps at 2688 x 1520
30 fps at 2560 x 1440
30 fps at 1920 x 1080
30 fps at 1280 x 960
30 fps at 1280 x 720
30 fps at 640 x 480
Multi-Streaming Simultaneous quad streams
Bit Rate 128Kbps - 12Mbps (per stream)
Bit Rate Mode Constant, Variable
Wide Dynamic Range Extreme WDR (150 dB)
Image Enhancement White Balance, Backlight compensation, Brightness, Contrast, Sharpness, Automatic gain control, Defogging
Digital Noise Reduction 3D DNR
Privacy Mask Yes
Text Overlay Yes
Built-in Analytics Tampering Detection*, Face Detection*, Object Line Crossing Detection*, Object Enter Area Detection*
Server-based Analytics Object Line Counting, People Counting, Face Detection, Object Based Motion Detection, Tamper, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Smoke Detection, Heat Map, Dwell Time, Direction Detection, Automatic License Plate Recognition, People Queue Detection, (Require PC-based or standalone IVS or ALPR Server. Contact ACTi support for recommendations on how to maximize analytical accuracy)
Image Orientation Flip, Mirror, Rotation

Audio

Network

Network Protocol & Service IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X
Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
Security IP address filtering, HTTPS encryption, Password protected user level, Anonymous login, IEEE 802.1X network access control

Event

Event Trigger Video motion detection (10 included or excluded regions), Tampering detection

Integration

GPS Position Manual setting
ONVIF Compliant Yes, Profile S, Profile G, Profile Q, Profile T
Web Browser IE 11
Auto Firmware Upgrade Yes

Interface

Local Storage MicroSD, MicroSDHC, MicroSDXC Memory Card Slot (card not included, up to 128GB)

General

Power Source DC 12V, PoE Class 3 (IEEE802.3af)
Power Consumption 6 W (DC), 7.5 W (PoE)
Weight 420g (0.9lb)
Dimensions (Ø x L): 70mm x 155.03mm (2.8" x 6.1")
Environmental Casing Weatherproof (IP67), Vandal proof metal casing (IK10)
Operating Temperature -30°C ~ 60°C (-22°F ~ 140°F)
Approvals CE, FCC, IP67, IK10 (metal casing)
Warranty 3 Year(s)
Comments * To be available through future firmware upgrade

Photo Indication

  1. Ethernet Port
  2. DC 12V Power Input
  3. Reset Button
  4. Memory Card Slot
